.338 LAPUA MAG AMMO
In Stock .338 LAPUA MAG Ammo For Sale- Trusted Ammo Retailers
.338 Lapua Magnum is a rimless, bottlenecked, centerfire rifle cartridge. It was developed during the 1980s as a high-powered, long-range cartridge for military snipers. It was used in the Afghanistan War and the Iraq War. As a result of this, it became more widely available.
In 1983, Research Armament Industries in the United States began the development of a new, long-range sniper cartridge capable of firing a 16.2-gram, 0.338-inch diameter bullet at 914 meters per second that could lethally penetrate five layers of military body armor at 1,000 m.
The loaded cartridge is 14.93 mm (0.588 in) in diameter (rim) and 93.5 mm (3.68 in) long. It can penetrate better-than-standard military body armor at ranges up to 1,000 meters and has a maximum effective range of about 1,750 meters with C.I.P. conform ammunition at sea level conditions.
About: .338 Lapua Mag
- Type: Rifle
- Place of origin: Finland
- Used by: Multiple official and civil users
- Designer: Nammo Lapua Oy
- Designed: 1989
- Produced: 1989–present
Specifications
- Parent case: .416 Rigby, .338/416
- Case type: Rimless, bottleneck
- Bullet diameter: 8.58 mm (0.338 in)
- Neck diameter: 9.46 mm (0.372 in)
- Shoulder diameter: 13.82 mm (0.544 in)
- Base diameter: 14.91 mm (0.587 in)
- Rim diameter: 14.93 mm (0.588 in)
- Rim thickness: 1.52 mm (0.060 in)
- Case length: 69.20 mm (2.724 in)
- Overall length: 93.50 mm (3.681 in)
- Case capacity: 7.532 cm3 (116.24 gr H2O)
- Rifling twist: 254 mm (1-10")
- Primer type: Large rifle magnum
- Maximum pressure: 420.00 MPa (60,916 psi)
Ballistic performance
| Bullet mass/type | Velocity | Energy |
|---|---|---|
| 12.96 g (200 gr) SP | 1,023 m/s (3,360 ft/s) 6,734 | J (4,967 ft⋅lbf) |
| 16.20 g (250 gr) Partition | 921 m/s (3,020 ft/s) 6,875 | J (5,071 ft⋅lbf) |
| 16.20 g (250 gr)Lapua | 925 m/s (3,030 ft/s) 6,925 | J (5,108 ft⋅lbf) |
| Scenar GB488 VLD | ||
| 19.44 g (300 gr) Sierra | 851 m/s (2,790 ft/s) 7,045 | J (5,196 ft⋅lbf) |
| HPBT MatchKing | ||
| 19.44 g (300 gr) Lapua | 847 m/s (2,780 ft/s) 6,971 | J (5,142 ft⋅lbf) |
| Scenar GB528 VLD |
